Invertek Drives Optidrive E3 ODE-3 Series User Manual page 40

Modbus CAN
RTU Open
Register Index
- 27DEh
- 27DFh
- 27E0h
- 27E1h
- 27E2h
- 27E3h
- 27E4h
- 27E5h
- 27E6h
- 27E7h
- 27E9h
- 27EBh
- 27ECh
- 27Edh
- 27EEh
- 27EFh
- 27F0h
- 27F1h
- 27F2h
- 27F3h
- 27F4h
- 27F5h
- 27F6h
- 27F7h
- 27F8h
- 27F9h
- 27FAh
- 27FBh
- 27FCh
- 27FDh
- 27FEh
- 27FFh
- 2800h
- 2801h
- 2802h
- 2803h
- 2804h
- 2805h
- 2806h
- 2807h
- 2808h
- 2809h
- 280Ah
11
40 | Fieldbus Guide | Version 1.00
Sub PDO Parameter
Index Map Number
0 N P0-23
0 N P0-23
0 N P0-24
0 N P0-24
0 N P0-27
0 N P0-27
0 N -
0 N -
0 N -
0 N -
0 N P0-28
0 N P0-28
0 N P0-19
0 N P0-19
0 N P0-19
0 N P0-19
0 N P0-19
0 N P0-19
0 N P0-19
0 N P0-19
0 N P0-15
0 N P0-15
0 N P0-15
0 N P0-15
0 N P0-15
0 N P0-15
0 N P0-15
0 N P0-15
0 N P0-16
0 N P0-16
0 N P0-16
0 N P0-16
0 N P0-16
0 N P0-16
0 N P0-16
0 N P0-16
0 N P0-17
0 N P0-17
0 N P0-17
0 N P0-17
0 N P0-17
0 N P0-17
0 N P0-17
Upper byte Lower Byte Format
Time Heatsink > 85C – Hours
Time Heatsink > 85C -
Seconds
Time Internal > 80C – Hours
Time Internal > 80C - Seconds
Fan Run Time – Hours
Fan Run Time - Seconds
Fire Mode Active Time – Hours
Fire Mode Active Time -
Seconds
Power on Time – Hours
Power on Time - Seconds
IO Checksum
DSP Checksum
Ambient Temperature Log 1
Ambient Temperature Log 2
Ambient Temperature Log 3
Ambient Temperature Log 4
Ambient Temperature Log 5
Ambient Temperature Log 6
Ambient Temperature Log 7
Ambient Temperature Log 8
DC Bus Voltage Log 1
DC Bus Voltage Log 2
DC Bus Voltage Log 3
DC Bus Voltage Log 4
DC Bus Voltage Log 5
DC Bus Voltage Log 6
DC Bus Voltage Log 7
DC Bus Voltage Log 8
Heatsink Temperature Log 1
Heatsink Temperature Log 2
Heatsink Temperature Log 3
Heatsink Temperature Log 4
Heatsink Temperature Log 5
Heatsink Temperature Log 6
Heatsink Temperature Log 7
Heatsink Temperature Log 8
Motor Current Log 1
Motor Current Log 2
Motor Current Log 3
Motor Current Log 4
Motor Current Log 5
Motor Current Log 6
Motor Current Log 7
Type Scaling
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
U16 R 1 = 1 Hour
U16 R 100 = 100 Seconds
WORD R
WORD R
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
U16 R 600 = 600 Volts
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
S16 R 50 = 50°C
U16 R 1dp, e.g. 100 = 10.0A
U16 R 1dp, e.g. 100 = 10.0A
U16 R 1dp, e.g. 100 = 10.0A
U16 R 1dp, e.g. 100 = 10.0A
U16 R 1dp, e.g. 100 = 10.0A
U16 R 1dp, e.g. 100 = 10.0A
U16 R 1dp, e.g. 100 = 10.0A
