Functional Principle, Technical Data
2.4

Technical Data

Controller
Speed range (measuring range)
Start of measuring range
Frequency response (-3dB)
Linearity
Target material
Supply voltage
Digital output
Analog output
Connection
Storage
Temperature range
Operation
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Material
Weight
Rotary switch
Control and display elements
FSO = Full Scale Output
1) Depends on sensor and target geometry; reference value for CS025/M5-CAm1,0/RS (capacitive rotary speed sensor) and electrical-
ly conductive target; with non-conductive materials, shorter measurement distances are required depending on the material
2) Relates to analog output; digital output without limitation
3) Up to an ambient temperature of max. 50 °C
capaNCDT CST6110
CST6110
1 ... 400,000 rpm
max. sensor distance from measuring object 1 mm
110 kHz
2
< ± 0.2 % FSO
Electrically conductive / non-conductive
11 ... 32 VDC, < 0.8 W
TTL level (1 pulse / detection with variable pulse duration or
1 pulse / rotation with 100 µs pulse duration)
0...5 V (short circuit proof)
Sensor: triax connector
Supply/signal: 6-pole connector (suitable connection cable SCAC3/6/IP included)
-40 ... +85 °C (-40 ... +185 °F)
-40 ... +85 °C (briefly up to 125 °C)
20 g / 5 ms in 3 axes, 1000 shocks each
10 g / 10 ... 2000 Hz in 3 axes, 10 cycles
IP67 (with closed lid and when connected)
Aluminum die-cast
approx. 165 g
1 ... 16 (adjustable via rotary switch)
Color LED indicates mode and measurement (red, blue, green and mixed colors)
1)
3
