Output Test

The controller provides a test signal at Pin 3 and 5 of the installed 6-pole POWER/SIGNAL socket. The measuring object does not have
to move in this operating mode.
The signal can be used to check the wiring of the measuring system structure.
Procedure:
Set the MODE switch to position 1.
The Status LED blinks Green – Blue – Red ... in sequence
The Analog and TTL outputs provide signals corresponding to the measuring object
out out
divider (BLADES) setting.
Pin 3, analog output {1 V / 1.5 V / 2 V ... 5 V} for measuring object dividers from 1 ... 10
{0 V} for measuring object dividers from 11 ... 16
Pin 5, TTL pulses t
i
Measuring object
t in µs t
i
divider
1 100
2 100
3 100
4 100
5 100
6 100
7 100
8 100
Fig. 23 Intervals of pulse pause for measuring object divider (BLADES)
capaNCDT CST6110
approx. 100 µs, t varies depending on the measuring object divider
p
in µs Frequency Measuring object
p
in Hz divider
4364 224 9
3965 246 10
3688 264 11
3397 286 12
3105 312 13
2815 343 14
2532 380 15
2242 427 16
in µs Frequency
t in µs t
i p
in Hz
100 1953 487
100 1667 566
100 1377 677
100 1090 840
100 802 1109
100 513 1630
100 225 3073
100 12 8944
Fig. 22 Settings of the MODE
switch for the output test
t t
i p
50 µs/DIV
TTL signal with measuring
object divider = 15
