MICRO-EPSILON capaNCDT CST6110 Operating Instructions Manual page 9

Functional Principle, Technical Data
Sensor
Measuring range
Linearity
Connection
Mounting
Storage
Temperature range
Operation
Humidity
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Material
Weight
Compatibility
capaNCDT CST6110
CS025/M5-CAm1,0/RS
0.25 mm
< ± 0.2 % FSO
Integrated cable with thermal protection hose, length 1 m;
minimum bending radius: static 7 mm, dynamic 25 mm
Screw connection via M5 thread
-50 ... +125 °C (-58 ... +257 °F)
-50 ... +125 °C
0 ... 95 % r.H. (non-condensing)
50 g / 5 ms in 3 axes, 1000 shocks each
30 g / 10 ... 2000 Hz in 3 axes, 10 cycles
IP67 (when connected)
1.4301 (non-magn.)
approx. 32 g
Compatible with capacitive CST controllers from Micro-Epsilon
Page 9
