2 SPECIFICATIONS

2.1 PROCESSOR

Description
iMX6 Quad Microcontroller
Speed

2.2 MEMORY

Description
Flash
RAM

2.3 DC SUPPLY

Description
Operating Voltage (Pin A7)
Maximum Current (Full Backlight, no External Loads)
Maximum Current (After Controlled Shutdown with Ignition off)

2.3.1 FUSING

Description
A1
A2
A3
A6
B1
B9
B10

2.4 ENVIRONMENTAL

NOTE: M12 protection plugs (supplied) must be installed in both the USB and Ethernet
interfaces to ensure IP67 rating when the connectors are not in use. Tighten to 0.8 Nm (0.6 lbf
ft). Where IP protection is required when the interfaces are in use, suitable O-rings must be
fitted.
Description
Operating Temperature
Storage Temperature
Degrees of Protection Provided by Enclosure
(With All Mating Connectors Fitted)
Specifications
ECU Supply
Wake Up
Ignition (15)
Program Enable
I/O Supply
I/O Supply
VREF Auxiliary Supply Output
Page 9 of 50
Specification
ARM A9
1 GHz
Specification
12.5 GB available for application.
16 GB total.
2 GB
Specification
8 V to 32 V
<1000 mA
<50 mA
Specification
3 A Max
1 A Max
1 A Max
1 A Max
8A or 16 A Max. See note above.
8 A or 16 A Max. See note above.
100 mA Max
Specification
-20 ºC to +70 ºC
(-4 ºF to 158 ºF)
-30 ºC to +80 ºC
(-22 ºF to 176 ºF)
IP67
(NEMA 6)
057-317 ISSUE: 1.1
