2.8 OUTPUTS

2.8.1 VREF OUTPUT SUPPLY

Description
Applicable Pins
Voltage
Max Current

2.8.2 HIGH SIDE FIXED

Description
Applicable Pins
Maximum Current
Digital Output Active Low 'ON' State Maximum Voltage at
Rated Current
Digital Output Active Low 'OFF' State Leakage Current

2.8.3 LOW SIDE / HIGH SIDE CONFIGURABLE

Description
Applicable Pins
Maximum Current
Digital Output Active Low 'ON' State Maximum Voltage at
Rated Current
Digital Output Active Low 'OFF' State Leakage Current
2.8.4 P.W.M. HIGH SIDE
Description
Applicable Pins
Maximum Current
Digital Output Active Low 'ON' State Maximum Voltage at
Rated Current
Digital Output Active Low 'OFF' State Leakage Current
PWM Frequency
Duty Cycle Resolution
Duty Cycle Precision
Specifications
Specification
Pin B10
Programmable 5 V / 10 V (±5 %)
100 mA
Specification
Pins B2, B3
2 A
<2 V
<10 mA at 24 V output supply
Specification
Pins B6, B7, B19, B20
2 A / 4 A Configurable
<2 V
<10 mA at 24 V output supply
Specification
Pins B2, B3
2 A
<2 V
<10 mA at 24 V output supply
20 Hz to 250 Hz
0.1 %
0.1 % (<=250 Hz), 1 % (>250 Hz)
Page 15 of 50 057-317 ISSUE: 1.1
