3.4 TYPICAL CONNECTION DIAGRAM

Terminology
Meaning
QCxxx
Output
ICxxx
Input
H
Output, High when active
L
Output, Low when active
AIN, FREQ
Input configurable to accept signals as positive digital, negative digital, 0 V to 5 V,
0 V to 10 V, 0 V to 32 V, 0 mA to 20 mA, 4 mA to 20 mA, ratiometric or resistive
and frequency measuring.
Installation
Page 27 of 50
057-317 ISSUE: 1.1
