2.7.5 ANALOGUE INPUTS
2.7.5.1
VOLTAGE
Description
Applicable Pins
Configurable Ranges
Resolution
Accuracy
Input Resistance
Sampling Rate
2.7.5.2
CURRENT
Description
Applicable Pins
Configurable Ranges
Input Type
Input Sink Resistance
Sampling Rate
Resolution
Accuracy
2.7.5.3
RESISTIVE
Description
Applicable Pins
Measurement Range
Measurement Source Voltage
Measurement Source Current
Sampling Rate
Resolution
Accuracy
2.7.5.4
RATIOMETRIC
Description
Applicable Pins
Measurement Voltage Reference
Measurement Type
Measurement Source Current
Accuracy
057-317 ISSUE: 1.1
Specifications
Specification
Pins B13, B14, B17, B18, B21, B22
0 V to 5 V
0 V to 10 V
0 V to 32 V
12 bits
± 2 % F.S.D.
>=30 kΩ
2 mS
Specification
Pins B13, B14, B17, B18, B21, B22
0 mA to 20 mA
4 mA to 20 mA
Current sink only
120 Ω ± 1%
2 mS
12 bits
± 1 % F.S.D.
Specification
Pins B13, B14, B17, B18, B21, B22
0 Ω to 3400 Ω
12 V maximum
1 mA
2 mS
12 bits
± 1 % F.S.D.
Specification
Pins B13, B14, B17, B18, B21, B22
Supply / VREF Output
Ratio of input Pin to Supply
1 mA
± 1 % F.S.D.
Page 14 of 50
