4.4.2.3

KEYBOARD BACKLIGHT

NOTE: Applicable only to DSEM812 Fascia Button variant.
Adjusts the default setting for the backlight of the fascia buttons.
The application may also adjust the button backlight after the power up sequence and application
start-up has completed.
4.4.2.4

REAL TIME CLOCK

Allows setting of the device Real Time Clock / Calendar.
4.4.2.5

PASSWORD

Allows password protection to be placed on the device. This prevents operations such as Format,
Clone, and Recover unless the password is known.
4.4.2.6

IGNITION

NOTE: Shutdown is not possible if the Wakeup pin is active.
Allows setting of the Ignition Pin timer.
Setting
Enable Timeout
Timer
Operation
Description
: The timer is disabled (Off)
: The timer is enabled (On).
NOTE: Ignition removal begins the timer
after which the device powers down. During
this delay WakeUp functionality is disabled.
Where the application requires WakeUp
functionality, it is recommended to keep this
timer to a minimum (minimum setting is 2
seconds).
The timer begins upon removal of the Ignition
pin. Shutdown sequence begins upon timer
expiry.
