3.5 USER CONNECTIONS
NOTE: If a prewired connection cable is used, remove the cores with unused signal inputs
and outputs. Unused cores, in particular core loops, lead to interference coupling that can
influence the connected controller.
NOTE: Connectors A and C are coded differently. Do not try to force a connector into the
wrong socket.
NOTE: USB and Ethernet connectors are coded differently. Do not try to force a connector
into the wrong socket.
Connector B (I/O)
Connector A (DC Supply, CAN & Cameras)
057-317 ISSUE: 1.1
Installation
Pressure Valve
Page 28 of 50
WiFi
USB
Ethernet 2
Ethernet 1
G.P.S.
