2.7.2 IGNITION(15)

NOTE: Either Wake-Up OR Ignition initiates the start-up process. Both must be removed
to allow shutdown to commence.
NOTE: Application of Wake-up (Pin A2) wakens the device, allowing for faster application
start upon Ignition application.
NOTE: Ignition removal begins the Ignition Off timer after which the device powers down.
During this delay Wake Up functionality is disabled. Where the application requires Wake Up
functionality, it is recommended to keep Ignition timer to a minimum (minimum setting is 2
seconds).
NOTE: Ignition Off timer is available within System Pages. For further details, see section
System Pages | Configuration | Settings | Ignition elsewhere in this document.
With ECU power on, a +ve signal on A3 initiates the start-up sequence.
Removal of Ignition, for longer than the configurable timer, initiates shutdown (providing Wake-up is
already removed).
This pin is intended to be driven by an external ignition switch or a signal from an external device
such as a schedule timer or a controlling PLC.
Description
Applicable Pin
Time between removal and shutdown
057-317 ISSUE: 1.1
Specifications
Specification
Pin A3
Factory Setting 0 s.
For details of timer adjustment, see section System
Pages | Configuration | Settings | Ignition
elsewhere in this document.
