2.9.7 CAMERA INPUTS

NOTE: Cameras Inputs provide facility for viewing only. Logging to file is not supported.
Description
Number of Camera Inputs
Applicable Pins
Camera Type
Interface Type
Overlay Size (when utilised)

2.9.8 IP CAMERAS

NOTE: IP Cameras provide facility for viewing only. Logging to file is not supported.
Description
Number of Supported IP Camera
Connection Method
Supported Protocols (RTP and RTSP)
Specifications
Specification
4
A4, A5 (Camera 1)
A7, A8 (Camera 2)
A13, A14 (Camera 3)
A15, A23 (Camera 4)
VGA
Analogue (Composite) Video for PAL / NTSC
1280 px X 800 px
Specification
4
Ethernet
H.264
MPEG-4
Page 19 of 50 057-317 ISSUE: 1.1
