Touchscreen Test
Touch the screen with one or more fingers to see the device detect the press and illuminate the
screen where the finger(s) touch.
Camera Test
Shows the signal detected on the four Analogue Camera (composite video) inputs.
IP Camera Test
NOTE: While Camera Test application allows for testing of two IP cameras, DSEM812
supports up to four (4) IP Cameras within the application.
Parameter
URL
Play
Inputs Test
Select the input to view by touching it on the screen, then select the configuration for the selected
input.
Parameter
Voltage
Current
Resistive
Frequency
For testing purposes, a moving graph of the input value is shown below the input measurement.
Outputs Test
Select the output to view by touching it on the screen, then select the configuration for the selected
output (High Side or Low Side).
Parameter
Enable
Operation
Description
Touch and enter the URL of IP Camera 1 or IP
Camera 2
Press Play to connect to and display the
selected IP Camera.
Description
Select the voltage range of the input:
5V: Input is configured to be 0 V to 5 V dc.
10V: Input is configured to be 0 V to 10 V dc.
32V: Input is configured to be 0 V to 32 V dc.
Input is configured to be 0 mA to 20 mA.
Input is configured to be 0 Ω to 3400 Ω.
Input is configured to be Digital and used to
measured the frequency of the input signal.
Description
: The output is enabled (On).
: The output is disabled (Off)
