4.4.1.2

HARDWARE INFORMATION

Provides useful information regarding the device hardware.
Parameter
CPU Temperature
PCB Temperature
Battery Voltage
I/O Voltage
RAM Usage
Storage Usage
Unique ID
4.4.1.3

NETWORK INFORMATION

Network Information is further separated into submenus:
Ethernet 1 Information
CAN1 Information
Ethernet 1 & 2 Information
Parameter
Cable Connected
MAC Address
DHCP
Continued overleaf...
Operation
Description
Internal temperature of the main CPU within the
device.
Temperature within the device, taken from a
sensor mounted on the device circuit board.
Measurement of the ECU Supply of the device.
Measurement of the I/O Supply of the device.
Shows internal RAM memory usage.
Shows device storage usage.
A unique ID given to the device. Used for
example,in USB communications.
Ethernet 2 Information
CAN2 Information
Description
No:No active ethernet is detected.
Yes: Active ethernet cable is detected on the
network interface.
Hardware address of this network interface.
No: Dynamic Host Configuration Protocol is not
enabled for this port. Static network settings are
in use.
Yes: Dynamic Host Configuration Protocol is
enabled. Ensure a DHCP server is active on this
network interface.
Page 35 of 50
WiFi Information
CAN3 Information
057-317 ISSUE: 1.1
