3 INSTALLATION
3.1 DIMENSIONS AND MOUNTING
3.1.1 DIMENSIONS
Description
Overall Dimensions (Height x Width x Depth)
M870 Without Buttons
Overall Dimensions (Height x Width x Depth)
M870 With Buttons
Mounting Type
Overall Weight
Installation
Specification
330 mm X 210 mm X 59.7 mm
(12.99 " X 8.27 " X 2.35 ")
330 mm X 210 mm X 63.5 mm
(12.99 " X 8.27 " X 2. 5 ")
8 x mounting bolts or RAM mount.
2.12 kg
(4.66 lb)
Page 21 of 50
057-317 ISSUE: 1.1
