4 OPERATION

NOTE: Ensure the System Pages are closed (exited) before attempting to send the
application to the device.

4.1 NAVIGATION AND SELECTION

Simply touch the icon on the screen to select the options.
Within the System Pages, the following icon appears in the display bottom left when available,
Icon Description
Press to save changes on this page and return to the previous page.
Press to return to a previous page, any changes that have been made are NOT
saved.
The adjacent option is selected. Touch the icon to toggle the selection.
The adjacent option is NOT selected. Touch the icon to toggle the selection.
4.2 SYSTEM PAGES
NOTE: Failure to select between Recovery and Configuration within 30 seconds results in
Recovery being selected.
NOTE: With DSEM812 with Buttons, Recovery is accessible directly by pressing and
holding any THREE fascia buttons at device power-up.
The System Information and System Settings pages are accessed as follows:
DSEM812 With Buttons
DSEM812 Without Buttons
Operation
•
Power off the device.
•
Press and hold any two buttons to access the setup
menu. (Press and hold any three buttons to access
Recovery directly, bypassing the setup menu).
•
Power on the device. Keep the buttons held until the
menu is displayed.
Alternatively, you may use the Program Enable Pin as
detailed below for the variant without buttons.
•
Power off the device.
•
Enable the Program Enable pin (A6)
•
Power on the device.
•
After a short while the Start-up Menu appears.
Page 31 of 50 057-317 ISSUE: 1.1
