4.4.3.4

CLONE

NOTE: Clone is applicable to DSEM812 CODESYS variant only.
NOTE: If configured, the device Password is required to access this section.
NOTE: When obtaining the Clone file from an existing device, ALL files on the device are
copied. For this reason, ensure the device was previously Formatted before the application
was installed. This ensures that the device contains only the required application and that
other (previously installed) files have been removed. For details on erasing a device, see
section entitled Format elsewhere in this document.
Where an existing device has the application already installed. Clone may be used to copy the entire
device contents.
This file may then be used to recover the device, or create Clones, sending the file to other devices.
Parameter
Select a Clone Method
057-317 ISSUE: 1.1
Operation
Description
Touch the screen to select the required option and press
continue.
Application Only: Only the application itself is copied.
Application & Retained Data: Only the Application and
Persistent/Retained Data is copied.
All: The Application, Persistent/Retained Data and all other
files present on the device are copied.
If the USB device is not connected or not detected, a red USB
icon is shown.
Connect USB memory stick to store the Clone file on.
A green USB icon shows that the USB device is detected.
Navigate the file system to select the directory to save into.
usbhd-sda1: The name of DSEM812 USB port. Press it to
select the USB device and view the contents.
If required, select a subdirectory. Press .. (two dots) to go
back up one subdirectory level.
Press to continue.
Circle animation is displayed during the process followed by a
confirmation message. Press OK to complete and return to
the USB directory listing.
Another Clone file can be made if required, alternatively, press
to return to the Device Control menu.
