17-3

Managing Files

Access the File Manager screen by pressing the File (#1) key on the data keypad. From this screen, you
may view the system configurations, measurement data, images, and other files currently saved to the
instrument or a connected USB device.
You can organize, move, or delete these files as desired.
17-3.1 — Viewing Files
Like the File Save screen (see Section 17-2), the File Manager screen has fields for file name, file type, and
location. Here, they are best navigated in reverse order: first Location, then Type, then Filename.
Location
Contains two softkeys: Local Disk and USB Disk. Tap a softkey to choose which disk to read files on: the
instrument's internal memory or a connected USB device.
Type
Contains five softkeys:
Setup. Setup configuration files can include active measurement mode of the instrument,
•
frequency/distance, marker placement, and other parameters and calibration data.
Meas. Measurement files contain all information in the current field and the measurement data.
•
Trace.Trace files contain saved measurement traces.
•
Report. Report files contain reports based on collected trace data. Reports can be generated
•
using the Deviser Site Workbench Software; please see Chapter 9 – Deviser Software Tools for
more information.
Image. The ScrnShot function saves a screenshot of the current display and saves it as an image.
•
The image can be previewed from the instrument using the Preview softkey in the top right-hand
corner of the File Manager display.
Tap a softkey to view all the files of that type stored on the disk.
File Name
Displays the currently selected file's name.
The files meeting your specifications will appear in the list below these fields. Tap a file's name to select it for
further action. You can also rearrange files, using the instrument's navigation tools (see subsection 17-3.3) or
the sortbar that runs horizontally above the file list. The sortbar contains headers such as file name, size, and
save date (when the file was created or modified). Use these headers to change the order of the file list
based on alphabetical order, age, etc.
For example, tap "File Size" once and an up-arrow will appear. This indicates that your files are now being
displayed according to size, from smallest to largest. Tap the key again to reverse the order and display
from largest to smallest.
Each file is listed with a checkbox icon under the column marked Selected. You can check multiple boxes
in order to select many files at once. (You cannot read/preview more than one file at a time.) Check the
box next to "Selected" to select all files in the list.
