Chapter 2 — Instrument Overview

Introduction

This chapter describes how to get started with the E7000L SitePROFILER Cable Analyzer. Topics covered in this
section include the following:

Unpacking the E7000L SitePROFILER

•
Powering on the E7000L
•
Exploring the E7000L
•
Display Overview
o
Front Panel Overview
o
Test Panel Connector Overview
o
Symbols and Indicators
o
Changing date and time
o
Changing distance units
o
About the Soft Carrying Case
•
2-1 Unpacking the E7000L SitePROFILER
Unpack and inspect the shipping package thoroughly to ensure that nothing was damaged during the
shipment. Also check that your delivered package includes all of your ordered items in the shipment.
If contents in the package are damaged or defective, or if there are missing items, keep the shipping list
and materials for the carrier's inspection and contact your nearest Deviser Instruments-authorized sales and
service office.
The E7000L should include the following items in the shipping package. For a comprehensive list of
compatible accessories, see Section 1-4.
2-2

Items included with E7000L shipment

Part Description
E7000L SitePROFILER Cable & Antenna System Analyzer
Rechargeable Li-Ion battery pack
AC/DC power adapter, 11-14 VDC
Automotive cigarette lighter adapter
"Y" OSL Calibration Device, N(m)
1.5m Test Port Extension Cable, 1.5m, N(m) to N(m), 6.0 GHz, 50Ω
LAN Ethernet Cable
CD-ROM User's Manual and Measurement Center Software
Soft Carrying Case
E7000L SitePROFILER
Part No.
E7000L
6130.0100.01
FSP065-RAB
E8000-0400
E7000-700
E7000-702
DS8831-706
E7000-0200
DS2800-008
Handheld Cable/Antenna Analyzer
Amt. Order No.
1 E7000L
1 6130.0100.01
1
1
1
1 6190.0501.03
1 6190.0500.19
1 6190.0600.40
1
