Front Panel Keys

The five main function menu keys are located to the right of the measurement display.
Menu
Pressing the Menu key opens up the desktop function and displays the Cable Analyzer measurement mode.
If other measurement modes have been installed on your E7000L, they will also be displayed on desktop. To
activate a specific measurement mode, simply touch the desired measurement mode icon on the desktop:
e.g., Cable Analyzer, Inline High Power Meter, etc.
Save
Pressing the Save key opens up the file save menu, enabling you to quickly label and save a measurement.
File types can be saved as a measurement setup, measurement or image. File names can be quickly
entered by using the pop-up touchpad. Shortcut, quick-label descriptions are also available by touching
page 1 or page 2 on the pop-up keypad.
Enter
Pressing the Enter key enters the final data input, or selects a highlighted item from a list.
Shift
Pressing the Shift key and then a number key executes the function that is located above the number key.
Esc
Pressing the Esc key will cancel (escape) any setting that is currently being made, or any dialog box that is open.
Rotary Knob
Turning the rotary knob changes the numerical values, scrolls through selectable items from a list, and
moves the markers left or right. Pressing the "ENTER" button at the center of the rotary knob enters data,
similar to the Enter button on the keypad.
