Data Keypad Function Keys

When in parameter-editing mode, the data keys are active and will enter the number printed on them.
Otherwise, pressing a number key executes the function that is located above the number key.
Measurement function keys are active when the instrument is not in parameter-editing mode.
System
Pressing System (#8) opens the System submenu. In this menu, you can set various system parameters,
display system info, and set system update. The system menu also allows you to change the date and time
setting to your preferred format.
Preset
Pressing Preset (#9) returns the E7000L SitePROFILER to factory settings and switches to Cable & Antenna
measurement mode.
ScrnShot
Pressing ScrnShot (#4) captures an image of the current display, saving it to internal memory as a bitmap
(.bmp) file. Files are automatically named based on the measurement type.
Trace
Pressing Trace (#5) opens the Trace submenu, enabling you to view the live trace and compare to a stored
trace in the memory. You can also employ the data math function to compare the two traces.
Limit
Pressing Limit (#6) opens the Limit submenu, enabling you to set measurement limit lines (including Pass/Fail
message limit lines). An audio limit alarm can be also be set to indicate that a measurement has exceeded
a preset limit condition.
File
Pressing File (#1) opens the File submenu, enabling you to quickly label and save a measurement. File types
can be saved as a measurement setup, measurement or image. File names can be quickly entered by
using the pop-up touchpad. Shortcut, quick-label descriptions are also available by touching X Name Page
1 or X Name Page 2 on the pop-up keypad.
Touch
Pressing Touch (#2) opens the touchscreen calibration function.
