11.2

Controls

Use the following rules to operate the NetGuardian's control:
1. Select Controls (or Exp. Controls) from the Monitor menu.
2. Under the State field, you can see the current condition of the control.
3. To issue the control, click on a command (OPR - operate, RLS - release, or MOM - momentary)
View and operate control relays from the Monitor > Exp. Controls menu
ID
Description
State
Command
Expansion Control Relay Operation
ID number for the control relay.
Description for the NetGuardian's control relay defined in the Provisioning > Controls
menu.
Status of the control relay. Can either be Released or Latched.
OPR - Latch the relay.
RLS - Release the relay.
MOM - Momentarily latch the relay, then automatically release the relay. The
duration of the latch is defined in the Provisioning > Controls menu.
53
