DPS Telecom NetGuardian 480 G3 User Manual page 53

ID Modbus register ID
Modbus Device Modbus device settings used when polling.
Description User0definable description for the Modbus register.
Notifications Check which notification device(s), 1 through 8, you want to send alarm
notifications for that Modbus register.
Qual. Time - Threshold must be crossede for this length of time before alarms is triggered. (set to 0
Qual. Type - Determines which actions Qual Time applies to.
Stable Frequency Frequency used when logging response history.
Register Number Register to be polled.
Number of Bits Number of bits used to mask the response value.
Integer/Float Interpret response value as an integer for a float.
Unsigned/Signed Interpret the response value as signed or unsigned.
Byte Order Byte ordering of response from Modbus device.
Scaling Scaling factor that the response value is multiplied by.
Units Units displayed with the response value.
MjU (Major Under) Threshold settings that, when crossed, will prompt the NetGuardian to set an
MnU (Minor Under) alarm. Recorded values less than an under value or greater than an over value
MnO (Minor Over) will cause alarms.
MjO (Major Over) NOTE: If the user has one of the Idle/Running threshold modes selected in
Device settings then there will be two sets of thresholds displayed here. If
Standard Thresholds is selected there will only be one.
Deadband The additional qualifying calue the NetGuardian requires above/below your
alarm thresholds in order to set an alarm.
Basic Configuration
Details
Function Code
Modbus function code to use when polling device
Event Qualification
to deactivate)
Recording Settings
Register Attributes
Thresholds
49
