Set Menu (SET)
---> Swapping Pan and Tilt (SWAP)
When you set this menu item to ON, the pan and tilt control channels will be swapped. Pan control will affect Tilt, and Tilt control
will affect Pan.
To apply Pan Tilt swap:
1. Press and hold <Menu> until AddR appears on the LED display.
2. Scroll to the SET menu. Press <Enter> to select.
3. Scroll to the SWAP menu press <Enter>.
4. Scroll to ON to swap the pan and tilt control channels.
5. Press <Enter> to store.
Mode Menu (MODE)
---> Firmware Cross Load (XLD)
The MMS200 fixture can crossload software from one fixture to additional MMS200 fixtures on the same DMX link.
To Cross Load Software:
1. Disconnect the data cable between the console and the first fixture
2. Press and hold <Menu> untilon the master fixture (the fixture with the latest software version) until the display changes
to AddR.
3. Scroll to the MOde menu. Press <Enter> to select.
4. Scroll to the XLD menu press <Enter>. The master fixture will upload its software to all connected fixtures on the DMX
link.
5. The Slave fixtures will display UPLD during this time. After the fixtures have completed the upload, they will reset and
home.
Notes: If the fixture(s) take longer than one minute to reset after an upload, turn off the fixture(s) and repeat the procedure. If a
new boot code was included with the latest software, you will need to store the boot code on each fixture.
