5 . 1 . 1 Configuration

The CONFIGURATION menu serves to adjust the FC01-Ex to its application within the entire
system.
During system configuration, measuring operations are not possible (see Appendix 1).
Configuration possibilities are:

5 . 1 . 1 . 1 Selection of monitoring head (menu option: SENSOR SELECT)

The menu covers only one calorimetric monitoring head type so that it is not necessary to enter
further details.

5 . 1 . 1 .2 Monitoring head data (menu option: SENSOR CODE)

To operate the FC01-Ex it is necessary to set sensor-specific characteristics.
These characteristics are specified by the sensor code which together with the monitoring head type
number is marked on the monitoring head housing.
Setting is menu driven in two steps:
1. Setting of the C characteristics
2. Setting of the T characteristics

5 . 1 . 1 .3 Medium selection (menu option: MEDIUM SELECT)

This menu option is used to select the medium in which the Flow Meter is used.
The following media are called:
* GAS
* FLUID

5 . 1 . 1 .4 Custom designed calibration (menu option: CUSTOMER TRIM)

5 . 1 . 1 .4 . 1 Access to menu option CUSTOMER TRIM

Access to the calibration menu is provided by answering CUSTOMER TRIM? with yes and
entering the fixed 3-digit ACCESS CODE.
Note:
Entering an incorrect code will cause skipping to the next option of the configuration menu; another
access to CUSTOMER TRIM can only be started after running through the entire configuration
menu.
FC01- Ex | Flow Meter
OPERATION
C range: 700 ... 1300
T range: 01 ... 99
ACCES CODE to be entered ➞ 987
41
