Flow Meter | FC01- Ex
Note:
q The measuring procedure necessitates a homogeneous distribution of substances/mixture.
Varying mixtures can only be detected by supervisory systems.
The particle size of class 2 media must not exceed 2 mm.
Medium:
Flow velocity:
Temperature differential:
Mass:
Specific heat:
Density:
Assignment table - Medium / Flow velocity / Temperature differential
Class/Medium
Class 1
a: air
oxygen
nitrogen
nitro oxide
carbon monoxide
deuterium
fluorine
hydrogen
hydrogen bromide
hydrogen chloride
hydrogen fluoride
hydrogen iodide
Class 2: We currently don't have much experience with the use of such media, but generally
the FC01-Ex can certainly be used.
Class 3
a: tap water
high-purity water
seawater
b: water glycol
(1:1 ... 2.5:1)
