Flow vision FC01-Ex User Handbook Manual page 19

Definitions and mounting instructions
1 2 3
1 2
XV
XSK - calorimetric monitoring head
XTF
Valid for all plug-in srew terminal strips:
Cable size:
Stripping length:
Clamping screw:
Contact material: pre-tinned tin bronze XV - Power supply
Connection by 3 pole connector; A
Pin No. Signal name
1 SGND
2 +U
V
3 -U
V
XTF - Keyboard release
Connection by 3 pole connector, factory-wired
Jumper 2-3 inserted = keyboerd blocked
FC01- Ex | Flow Meter
EX ATMOSPHERE
1 2 3 4 5
XV
XAS
3 4 5 6 7 8 1 2 3
- power supply
- keyboard release
0.14 mm² to 1.5 mm², single or stranded conductor
6.5 mm
M2 (nickel-plated brass)
= 1.5 mm
max
Function
general reference ground/shield ground
positive pole of supply voltage
negative pole of supply voltage
6 7 8 9 10 1 2 3
1
XSK XTF
XAO XAH
4 5 6 7 8 1 2 3 4 5
XAS - not released for user
XAO - analogue outputs
XAH - signal outputs
2 2
; 3 x 0.75 mm cable recommended
2 3 4
M
6 7 8
fig. 8
19
