Flow Meter | FC01- Ex

8 Technical data

8 . 1 Ambient conditions FC01-Ex

Storage temperature:
Ambient temperature: *
Degree of protection:
*Only if the modules are spaced at least 10 mm.

8 .2 Monitoring head CST-Ex

Temperature measuring range I (medium):
Temperature measuring range II (sensor):
Temperature measuring range III (cable):
Pressure resistance:
Degree of protection (housing)
Pollution degree (cable/head connection)
(to DIN VDE 0627)

8 .3 Electrical characteristics

8 .3 . 1 Power supply

DC supply
Pin selection:
66
TECHNICAL DATA
- 20 ... +70 °C
+10 ... +43 °C
IP54
-40 ... +75 °C
-30 ... +75 °C
-10 ... +80 °C
100 bar (1470 PSI)
IP67 (connection cable in locked
condition)
2
Signal name
+U
V
-U
V
Pin XV
2
3
