Assembly and operating instructions
Metering pump
Hydro/ 4, HA4a
in compliance with API 675
EN
Target group: trained, qualified personnel, unless otherwise required.
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.
999824
Original operating instructions (2006/42/EC)
BA HY 021 05/21 EN
