MAIN MENU: SUPPORT SURFACES

Air Mattress Options

The InTouch™ bed can detect if it is connected to a
mattress . It can also detect the typical Air Mattress
which is connected to it .
When the Support Surface button is pressed on the
main menu bar and there is no mattress connected to
the InTouch™, Figure 7 .0 will be displayed .

XPRT Mattress Specifications

Refer to the XPRT manual .
InTouch™ integrated with the XPRT Mattress
Siderail Position
The position of the siderails determines the
functionality of the XPRT mattress . All the therapies,
including Max Inflate, Firmness and Turn Assist, will
function if the siderails are unlocked, except for the
rotation therapy . If a siderail is unlocked during the
rotation therapy, this therapy will automatically stop .
If two therapies are simultaneously executed and a
siderail is unlocked during these therapies, they will
automatically stop . If one of the siderails is unlocked
during a rotation therapy (ex .: rotation and vibration
is being executed simultaneously), both therapies will
stop instantly .
www.stryker.com
Footboard Operation Guide
2131-009-005 REV A
No mattress detected.
Please check cable
connections
Figure 7.0
Status
Rotation
Rotation:
OFF
Percussion
Vibration
Percussion:
OFF
Max Inflate Vibration:
OFF
Firmness
Siderails Must be Up
When Patient is Unattended
Turn Assist
Unit/Rm :
Figure 7.1
Start
Stop
Oct. 25,2007 12:00 AM
Return To Table of Contents
1-39
