SPECIFICATIONS (CONTINUED)

Recommended Mattress Size
Mattress
Recommended Air Mattress Size
Without Optional Auxiliary Outlet
Maximum
(120VAC Only)
Current
With Optional Auxiliary Outlet(s)
Consumption
(120VAC Only)
Storage
• Ambient Temperature
• Relative Humidity
• Atmospheric Pressure
Environmental
Conditions
Operating
• Ambient Temperature
• Relative Humidity
• Atmospheric Pressure
All electrical requirements meet CSA
Electrical
C22 .2 No . 601 . 1 , UL 60601-1 and IEC
Requirements
60601-1 .60601-2-38 specifications .
12 V, 17 .6 Ahr, Sealed Lead-Acid Battery (Part Number QDF9188)
Battery 3 .0 V 220mAh Lithium Battery, Size 20mm - Varta Int . CR2032
Coin Cell PC Battery Holder, Size 20mm - MDP Int . BA2032
Stryker reserves the right to change specifications without notice.
Specifications listed are approximate and may vary slightly from unit to unit or by power supply fluctuations .

WARNING / CAUTION / NOTE DEFINITION

The words WARNING, CAUTION, and NOTE carry special meanings and should be carefully reviewed .
WARNING
Alerts the reader about a situation, which if not avoided, could result in death or serious injury . It may also describe
potential serious adverse reactions and safety hazards .
CAUTION
Alerts the reader of a potentially hazardous situation, which if not avoided, may result in minor or moderate injury to
the user or patient or damage to the equipment or other property . This includes special care necessary for the safe
and effective use of the device and the care necessary to avoid damage to a device that may occur as a result of use
or misuse .
Note
This provides special information to make maintenance easier or important instructions clearer .
Return To Table of Contents
1-6
Introduction
35" x 84" x 6"
35" x 84" x 6" - 8 .5"
4 .8 Amps
9 .8 Amps
-40°F to 158°F
10 to 100%
500 to 1060 hPa
50°F to 104°F
30 to 75%
700 to 1060 hPa
100V~, 50-60Hz, 7 .5A - Two 250V, 10A Fuses
120 ± 10% Vac, 50/60Hz - Two 250V, 10A Fuses
120V~, 50-60Hz, 4 .0A (9 .8A with 120V Optional Auxiliary
Outlet) - Two 250V, 10A Fuses
200V~, 50-60Hz, 3 .2A -Two 250V, 6 .3A Fuses
220V~, 50-60Hz, 2 .9A -Two 250V, 6 .3A Fuses
240V~, 50-60Hz, 2 . 7 A -Two 250V, 6 .3A Fuses
2131-009-005 REV A
88,9 cm x 213,4 cm x 15,2 cm
88,9 cm x 213,4 cm x
15,2 cm - 21,6 cm
-40°C to 70°C
10°C to 40°C
