3.18 Initial start-up
48
￭￭￭￭￭￭￭￭
3 Starting equilibration
Start the equilibration in MagIC Net: Workplace ▶ Run ▶ Equi-
￭
libration ▶ Start HW.
4 Deaerating the high-pressure pump
Push the end of the purge needle (6.2816.040) over the end of
￭
the purge capillary on the purge valve.
Insert the syringe (6.2816.020) in the Luer connector of the purge
￭
needle.
Open the purge valve using the rotary knob (approx. ½ turn).
￭
Switch on the high-pressure pump in MagIC Net.
￭
Use the syringe to aspirate eluent until there are no more air bub-
￭
bles in the eluent aspiration tubing.
Switch off the high-pressure pump in MagIC Net.
￭
Seal the purge valve using the rotary knob.
￭
Remove the syringe from the purge needle.
￭
Pull the purge needle out of the purge capillary.
￭
5 Rinsing the instrument without columns
Rinse the instrument (without columns) with eluent for 10
￭
minutes.
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
