3.13 Suppressor
32
￭￭￭￭￭￭￭￭
Insert the rotor into the adapter so that the tubing connections
￭
on the rear of the rotor fit into the corresponding recesses inside
the adapter and one of the 3 holes of the rotor is visible in the
slot of the adapter.
Inserting the adapter into the suppressor drive
1 Removing the union nut
Loosen the union nut and remove it.
￭
2 Inserting the rotor
Insert the adapter into the suppressor drive so that the tubing
￭
connections on the rear of the adapter fit into the corresponding
recesses inside the suppressor drive and one of the 3 holes of the
rotor is visible from below in the slot of the suppressor drive.
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
