3.15 Conductivity detector
1 Detector cable
With installed plug.
3 Type plate
With serial number.
44
￭￭￭￭￭￭￭￭
1
Figure 16 Rear of conductivity detector
NOTICE
In order to prevent unnecessary peak widening after separation, the
connection between the outlet of the separation column and the inlet
to the detector should be kept as short as possible.
Connecting the detector input capillary to the suppressor
1 Connect the detector input capillary (17-1) and the capillary of
￭
the MSM labeled out (17-2) to each other using a coupling
(6.2744.040) (17-3) and two short pressure screws (6.2744.070)
(17-4).
2 Detector output capillary
Permanently installed.
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
3
2
883 Basic IC plus
