3.7 Capillary and cable feed-throughs
Figure 6 Capillary feed-throughs on the door
1 Luer connector
For connecting a (6.2816.020) syringe. For
manual sample feeding.
3 PEEK pressure screw (6.2744.070)
22
￭￭￭￭￭￭￭￭
Do not feed capillaries through the Luer connectors (6-1). The capillaries
are fastened with PEEK pressure screws (6-3) from inside to the Luer con-
nector. From outside, liquid can be aspirated or injected with a syringe.
2 Capillary feed-through
4 Door
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
883 Basic IC plus
