Spanset PowerForce Original Operating Instructions page 28

or slide during the lifting process. This is especially true for smooth/
polished, as well as rough and sharp-edged surfaces.
– With a radius of >2 mm no additional edge protection is required.
As mentioned before, make sure that the strap is fixed in position,
preventing slipping on the edge!
– The lifting strap must be laid around the load without twisting so
that it carries with its entire width
– Never wrap the strap around the seams or attach in the area around
them.
– PowerForce loop and endless lifting straps should only be used in
the choke hitching procedures, as long as D1 and D2 straps are used
23
(PF D1D2).
– Otherwise, choke hitching is prohibited.
– The part of the load to which the PowerForce lifting strap is at-
tached must be capable of absorbing the applied force.
– Ensure that the size of the load-bearing points (e.g. on trusses) or
the crane hook is sufficient to prevent damage to the loops and
straps of the PowerForce lifting straps.
technical data in Table
Danger to life due to falling loads!
Danger of death or serious injury from falling loads when unsuitable
PowerForce lifting straps are selected or misused (see Points 4. to
4.4.3.) !
Death or serious injury to persons due to falling of the loads when
several different PowerForce lifting straps are used at the same time.
Use only identical PowerForce lifting straps.
Death or serious injury to persons due to falling of the loads when
tilted. When using multiple straps, use only SpanSet lifting straps
with the same expansion or same type.
b
4
.
.
V
DANGER
26
21
17
Also compare with the
