15.3 To unpack the outdoor unit

15.4 To remove the accessories from the outdoor unit

RXMLQ8 + RXYLQ10~14T7Y1B*
VRV IV system air conditioner
4P543427-1A – 2020.10
b Belt sling
c Opening
d Protector
NOTICE
Use a belt sling of ≤20 mm wide that adequately bears the weight of the unit.
▪ A forklift can only be used for transport as long as the unit remains on its pallet
as shown above.
Remove the packaging material from the unit:
▪ Take care not to damage the unit when removing the shrink foil with a cutter.
▪ Remove the 4 bolts fixing the unit to its pallet.
WARNING
Tear apart and throw away plastic packaging bags so that nobody, especially
children, can play with them. Possible risk: suffocation.
Make sure that all accessories are available in the unit.
