1
|
About the documentation
1 About the documentation
In this chapter
1.1 About this document
1.2 Meaning of warnings and symbols
Installer and user reference guide
6
1.1
About this document..............................................................................................................................................................
1.2
Meaning of warnings and symbols.........................................................................................................................................
Target audience
Authorised installers + end users
INFORMATION
This appliance is intended to be used by expert or trained users in shops, in light
industry and on farms, or for commercial use by lay persons.
Documentation set
This document is part of a documentation set. The complete set consists of:
▪
General safety precautions:
-
Safety instructions that you must read before installing
-
Format: Paper (in the box of the outdoor unit)
▪
Outdoor unit installation and operation manual:
-
Installation and operation instructions
-
Format: Paper (in the box of the outdoor unit)
▪
Installer and user reference guide:
-
Preparation of the installation, reference data,...
-
Detailed step-by-step instructions and background information for basic and
advanced usage
-
Format: Digital files on
product-information/
Latest revisions of the supplied documentation may be available on the regional
Daikin website or via your dealer.
The original documentation is written in English. All other languages are
translations.
Technical engineering data
▪
A subset of the latest technical data is available on the regional Daikin website
(publicly accessible).
▪
The full set of latest technical data is available on the Daikin Business Portal
(authentication required).
DANGER
Indicates a situation that results in death or serious injury.
http://www.daikineurope.com/support-and-manuals/
6
6
RXMLQ8 + RXYLQ10~14T7Y1B*
VRV IV system air conditioner
4P543427-1A – 2020.10
