Quick Start Guide
2.3

Hardware Setup Procedure

A typical test setup using the ADC32RFxx-EVM and TSW14J56EVM is shown in
setup used for the quick-start procedure.
Analog Input
Low-Noise
Signal Generator
2949.12 MHz, +15 dBm
2949.12-MHz
Analog Input Bandpass Filter
Low-Noise
Signal Generator
1900 MHz, +15 dBm
1900-MHz
Bandpass Filter
Figure 2. ADC32RFxx-EVM GUI Bench Setup Block Diagram
8
ADC32RFxx-EVM
Low-Noise
Power Supply
+5 VDC at 3 A
CLK
+5-VDC Power Supply Cable
AINP
ADC32RF45 EVM
Copyright © 2016–2017, Texas Instruments Incorporated
Figure
Mini-USB Cable
USB 3.0 Cable
Power
Switch
Low-Noise
TSW14J56EVM
Power Supply
+5 VDC at 3 A
SLAU620D – April 2016 – Revised August 2017
Submit Documentation Feedback
www.ti.com
2. This is the test
PC Running
HSDC Pro
