Quick-Start Procedure for Bypass LMFS82820 Mode in ADC32RF45
5. Click on the Quick Setup tab.
6. Select the Nyquist Zone for the input. It will be 2nd Nyquist in this example setup (Fs = 2949.12M, Fin
= 1900M).
Figure 4. ADC32RFxx-EVM Quick Setup View Bypass Mode
7. Select the Clock Source to ADC. In this example, External Clocking is selected.
8. Select ADC32RF45 Mode. In this example, Bypass is chosen.
9. Select Resolution. In this example, 12 bit is selected.
10. Press PROGRAM EVM.
