Slamtec APOLLO User Manual page 7

Charger indicators description:
Preset
Indicator
Condition
Charger
power on
Power
Charger
Indicator
power off
(charger)
Exceptions
Not charging
Charging
Fully charged Green light
indicator
Charging
(Power)
Exceptions
Figure 2-3 Apollo Charger Indicators Description
Charger ports description:
Name Parameter
Charging port 220-240VAC
Charging
25.2V 10A
electrode
Emergency
25.2V 10A
charging port
Firmware
USB
upgrade port
Figure 2-4 Apollo Charge Station Interface Description
Status Description
The charger is powered on
Red light
normally.
Light goes
The charger is power off.
out
Light flicks There are problems in the
or goes out charger.
Light goes The charger is not charging
out Apollo.
Apollo is fully charged.
Red light Apollo is charging normally.
Light flicks There are problems in the
or goes out charger.
Description
Provides power supply for the charger.
Provides contact charging for Apollo.
Provides charging for Apollo in
emergency, such as the charging
electrode not working.
Provides firmware upgrading for Apollo
charger.
7 / 25
