System Switch
Air switch
Figure 4-1 Apollo Air Switch and System Switch
3. Build and Save Map
Download and install the robot graphical tool RoboStudio from our official website
. Register and login to the tool. By clicking
http://www.slamtec.com/cn/RoboStudio
File->Robots in the menu, user can find a docked window opened in the left side
of the pane as in Figure 4-2. In this window, user can connect to or disconnect
from robots.
Figure 4-2 RoboStudio Robot Interface
Right click the whitespace of the robot list -> choose manual connect robot in
the prompt dialog box, -> enter the IP address and port number in the new dialog
box -> click Connect to connect to the robot as shown in the following screenshot.
If you have already connected to the SSID obtained in step 3 via network adapter
