Mounting procedure: dimensions, space and handling
3.5 Overall dimensions and installation space
D
B''' B'' B' B
E
Item
A
B 1110 mm (43.70 in)
B'
B''
B'''
C
C'
C''
D
E
F
26
required for the C5G (without conditioner)
1 2
A
E
C5G Control Unit version (without conditioner)
Standard With rising socket
(1)
-- 1210 mm (47.63 in)
--
--
3
F
With Application Box
(2) (3)
800 mm (31.49 in)
-- --
--
-- 1650 mm (64.96 in)
-- --
510 mm (20.08 in)
560 mm (22.05 in)
590 mm (23.23 in)
70 mm (2.75 in)
400 mm (15.75 in) *¹
200 mm (7.87 in) *¹
4
C
C'
C''
With rising socket
and Application Box
(4)
--
--
--
1750 mm (68.90 in)
