MOUNTING PROCEDURE:
DIMENSIONS, SPACE AND HANDLING
This chapter deals with the following topics:
– Precautions before starting the procedure
– Equipment and tools required
– Packing list check
– Weight and size including package
– Overall dimensions and installation space required for the C5G (without
conditioner)
– Overall dimensions and installation space required for the C5G (with conditioner)
– Lifting and handling procedures
– Procedure to remove the crate, protection cloth and pallet
– Placing in position.
Before starting the handling procedure, please read carefully the notes in
Chap. Installation instructions on page
– Lifting equipment suitable for the installation area (crane or lift truck)
– Eyebolts (supplied together with the Control Unit and already fastened on the
cover, featuring EC mark).
– 13-mm socket wrench
Inside the cabinet is a STANDARD PRODUCT LIST.
Make sure all components in the list are available.
