3.4.2 C5G featuring rising socket

h
d
w
C
Supply
On pallet
modality
Weight
1200x800x1430 mm
Size *¹
47.2 x 31.5 x 56.3 in
*¹ approximate size (width x depth x height)
No package, without conditioner (C)
Weight
Size
Installation
position
HS-RC-C5E-TIN_02.fm
00/0411
A
B
Without conditioner (C)
In closed crate
(A)
157 kg 205 kg
346 lb 452 lb
1000x800x1500 mm
39.4 x 31.5 x 59.0 in
137 kg
302 lb
see par. 3.5
Mounting procedure: dimensions, space and handling
D
On pallet
(B) (A)
192 kg
423 lb
1200x800x1770 mm
47.2 x 31.5 x 69.7 in
No package, with conditioner (D)
With conditioner (D)
In closed crate
(B)
240 kg
529 lb
1000x800x1840 mm
39.4 x 31.5 x 72.4 in
172 kg
379 lb
see par. 3.6
