Mounting procedure: dimensions, space and handling

3.4.3 C5G featuring Application Box

A
h
w
d
C
Supply
On pallet
modality
Weight *¹
1200x800x1870 mm
Size *²
47.2 x 31.5 x 73.6 in
*¹ typical weight. It may differ depending on the equipment installed inside. Refer to the identification plate posted on the Application Box.
*² approximate size (width x depth x height)
No package, without conditioner (C)
Weight *¹
Size
Installation
position
*¹ typical weight. It may differ depending on the equipment installed inside. Refer to the identification plate posted on the Application Box.
24
B
Without conditioner (C)
In closed crate
(A)
180 kg 225 kg
397 lb 496 lb
1000x800x1900 mm
39.4 x 31.5 x 74.8 in
160 kg
363 lb
see par. 3.5
D
On pallet
(B) (A)
215 kg
474lb
1200x800x2210 mm
47.2 x 31.5 x 87.0 in
No package, with conditioner (D)
With conditioner (D)
In closed crate
(B)
260 kg
573 lb
1000x800x2240 mm
39.4 x 31.5 x 88.2 in
195 kg
430 lb
see par. 3.6
