3.4.4 C5G featuring rising socket and Application Box

A
h
w
d
C
Supply
On pallet
modality
Weight *¹
1200x800x1970 mm
Size *²
47.2 x 31.5 x 77.5 in
*¹ typical weight. It may differ depending on the fitting-out installed inside. Refer to the identification plate posted on the Application Box.
*² approximate size (width x depth x height)
No package, without conditioner (C)
Weight *¹
Size
Installation
position
*¹ typical weight. It may differ depending on the fitting-out installed inside. Refer to the identification plate posted on the Application Box.
HS-RC-C5E-TIN_02.fm
00/0411
B
Without conditioner (C)
In closed crate
(A)
195 kg 240 kg
430 lb 529 lb
1000x800x2000 mm
39.4 x 31.5 x 78.7 in
175 kg
386 lb
see par. 3.5
Mounting procedure: dimensions, space and handling
D
On pallet
(B) (A)
230 kg
507lb
1200x800x2310 mm
47.2 x 31.5 x 90.9 in
No package, with conditioner (D)
With conditioner (D)
In closed crate
(B)
275 kg
606 lb
1000x800x2340 mm
39.4 x 31.5 x 92.1 in
210 kg
463 lb
see par. 3.6
