CHAPTER 3 Physical Description
Item
#
1 -
2 SYS / TEL / PWR /

LED Descriptions

This section describes the LEDs on the front panel of the chassis.

SYS LED

The SYS LED indicates the device's operating status, as described in the following table.
Color
Green
Orange
Red

TEL LED

The TEL LED indicates the status of the FXS blades, as described in the following table.
Color
Green
Table 3-2: Front Panel Description
Label
Fan Tray cover. For more information, see
page 6 .
Front-panel LEDs. For more information, see
FAN Descriptions
Table 3-3: SYS LED Description
State
On LED lit as a result of one of the following:
■
Device is operating normally
■
During first stage of boot up when device is powered on
On Chassis is approaching high temperature threshold, but not yet critical
On LED lit as a result of one of the following:
■
Fault detected in CPU module
■
Incompatible or faulty software version (.cmp file) detected during
boot up
■
Approaching critical high temperature threshold
Off No power
Table 3-4: TEL LED Description
State
On LED lit as a result of one of the following:
MP-1288 | Hardware Installation Manual
Description
below .
Description
Description
- 4 -
Fan Tray on
LED
