CHAPTER 5 Cabling the Device
FXS Phone Channel
(Ports)
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25 for Analog Lifeline

Connecting FXS Interfaces using AudioCodes FXS Patch Panel

You can purchase AudioCodes' FXS Patch Panel (shown in the following figure) to connect the
FXS interfaces to FXS equipment. The patch panel can be mounted in a 19-inch rack using
integrated mounting brackets and provides a 2-meter (78.7 in.) extension cable with a 50-pin
male connector for connection to the FXS port on the FXS blade. All incoming wires from the
50-pin Telco connector are terminated to the back of the patch panel. The FXS endpoints (e.g.
telephones) can be plugged into the corresponding RJ-11 jacks on the front of the patch panel.
For analog Lifeline cabling, see
Lifeline on page 30 .
- 24 -
MP-1288 | Hardware Installation Manual
Connector Pins
10/35
11/36
12/37
13/38
14/39
15/40
16/41
17/42
18/43
19/44
20/45
21/46
22/47
23/48
24/49
25/50
Connecting the FXS Analog
