INSTALLATION
4.2

System Components

The 501 Analyzer benefits from a modular construction, with the major parts of the
analyzer shown below:
Figure 30
A Inputs (2 x 4–20 mA)
B Outputs (2 x 4–20 mA + RS485)
C Alarms (2 x concentration alarms)
D 24v Power connection
E Gas Inlet and Outlet
F Light Guide
G HMI
32
XTP501 & XTC501 User's Manual
A
B
C
D
XTP501 and XTC501 Showing Major Components
G
F
E
99976 Issue 1.1, May 2020
